PP Honeycomb Core

PP Honeycomb Core is a durable thermoplastic honeycomb material selected for its moisture resistance, chemical resistance, impact resistance, and long service life. Compared with paper-based core materials, polypropylene honeycomb is better suited for humid environments, repeated handling, and applications requiring stable performance in lightweight composite structures. It is commonly used in composite panels, RV panels, vehicle flooring, marine panels, partitions, industrial boards, logistics panels, filtration substrates, and other lightweight structural applications. Cell size, density, thickness, surface condition, and finished dimensions can be selected according to project requirements.

Request a Quote View Specifications
Product Form
Honeycomb Core
Supply Mode
Slice
Engineering
Custom Specs
PP Honeycomb Core
PP Honeycomb Core gallery image
PP Honeycomb Core gallery image

Product Overview

Engineered honeycomb material information for technical evaluation, procurement comparison, and project specification.

PP Honeycomb Core is a durable thermoplastic honeycomb material selected for its moisture resistance, chemical resistance, impact resistance, and long service life. Compared with paper-based core materials, polypropylene honeycomb is better suited for humid environments, repeated handling, and applications requiring stable performance in lightweight composite structures. It is commonly used in composite panels, RV panels, vehicle flooring, marine panels, partitions, industrial boards, logistics panels, filtration substrates, and other lightweight structural applications. Cell size, density, thickness, surface condition, and finished dimensions can be selected according to project requirements.

Core Features

01

5

Technical Specifications

Review available parameters and confirm project-specific requirements with our engineering team.

Confirm Custom Specs
PP Honeycomb Core technical specifications
Parameter Value Note
Cell Size 6mm / 8mm / 10mm
Density 75 / 80 / 90 kg/m³
Cell Wall Type Open / closed-cell
Core Thickness 8–100mm
Thickness Tolerance ±0.3mm
Standard Dimension 1220 × 2440mm Maximum: 1250 × 3000 mm
Service Temperature -40°C to 80°C
Surface Option With / without non-woven fabric and plastic film
Expansion Status Expanded Available forms may vary by material type.
Supply Form Slice Custom cutting available on request.

Application Scenarios

Typical use cases for lightweight structures, composite panels, industrial components, and engineered assemblies.

Customization Options

Mex-core supports custom honeycomb specifications including cell size, density, foil or paper thickness, panel configuration, dimensions, expansion status, surface treatment, and application-specific processing.

Recommended Inquiry Details

Cell size

Dneisty

Technical Resources

Access related documents, engineering notes, and technical references for product evaluation.

Need datasheet or technical support?

Send your project requirements and our team will provide suitable product data, specification guidance, and process recommendations.

Request Documents

Send Your Honeycomb Material Inquiry

Share your target cell size, thickness, density, dimensions, quantity, and application. Our engineering team will help confirm a suitable specification.
